CPU Support
LGA1151 socket for Intel® 6th Gen. Core™ i7/i5/i3 and Pentium/Celeron® processor
CPU
C236: E3-1275 v5, E3-1225 v5, E3-1268 v5, I3-6100(TE), H110/Q170: i7-6700(TE), i5-6500(TE), i3-6100(TE), Pentium G4400(TE), Celeron G3900(TE)
Chipset
Intel® C236 / H110 / Q170
DRAM
4 DDR4 UDIMM(C236:ECC/non-ECC)(Q170:non-ECC) | 2 DDR4 UDIMM(H110:non-ECC)
Watchdog
1~255 seconds watchdog timer selectable
Power Supply
ATX 24+ 4 power
Power Consumption
+5V:1.57A; +12V:5.09A; +3.3V:0.43A; +5VSB:0.16A (CPU: i7 6700 3.4GHz)
Dimension
305 x 244mm (12" x 9.6")
OS Support
Windows 10(64), Windows 8.1(64), Windows 7 Pro(32/64)
SATA Interface
6 x SATA III (6.0Gb/s) RAID 0,1,5,10 (C236 and Q170 SKU) | 4 x SATA III (6.0Gb/s) (H110 SKU)
Expansion BUS
1 PCIe (x16), 1 PCIe (x4)(C236/Q170=Gen3)|(H110=Gen2), 5 PCI, 1 miniPCIe,
Serial Port
6 x COM (C235=COM1~6, Q170=COM1~4, H110=COM1~2), COM1-6 for RS-232, COM2 for RS-232/422/485, COM3/4 supports 5V/12V
Keyboard/Mouse
2 x PS/2 with mini DIN connectors
FAN
1 x CPU fan, 2 x system fans
LAN
LAN 1: Intel® PHY I219 LM (10/100/1000 Mbps), LAN 2: Intel® LAN I211AT (10/100/1000 Mbps), Supports wake-on-LAN with ATX power
Audio
MIC / Line-in / Line-out ; High definition audio with Realtek ALC888S
USB
6 USB 3.0, 4 USB 2.0(C236/Q170) | 4 USB 3.0, 6 USB 2.0(H110)
